| Directional Jamming Unit Performance Parameters | |
| Interference band | 400MHz-6GHz full frequency band, support frequency band interval and custom interference signal frequency |
| Interference mode | Directional interference |
| Distance of interference | Orientation ≤4.9km* |
| Number of simultaneous interference bands | 6 |
| Single channel power | ≤0W |
| Interference pattern | Broadband suppression mode, sweep interference mode, narrowband aiming mode |
| Interference beam angle | ≤2掳 |
| Directional Navigation Decoy Unit Performance Parameters | |
| Interference pattern | Directional eviction, fixed-point emergency landing, regional no-fly zone |
| Navigation type | GPS/GLONASS/BDS/GALILEO |
| Distance of interference | Orientation: ≤4.9km (can be customized as omnidirectional)* |
| Tunable Unit and Machine Performance Parameters | |
| Rotational speed | Horizontal 0.1°~20°/s; Tilt 0.1°~5°/s |
| Pitch angle | +90°~-10° |
| Horizontal angle | Horizontal 0~360° continuous rotation |
| Deception signal intrusion time | ≤s* |
| Power supply mode | External power supply 220V, supports 7*24H |
| Equipment power | ≤500W (full power output) |
| Working temperature | -20°C~+70°C |
| Product weight | ≤5kg |
| Product size | L*W*H: 730mm * 470mm * 640mm (excluding adapters and antennas) |
