377.7 mm (length) × 416.2 mm (width) × 212.5 mm (height)
Wheelbase
498.5 mm
Maximum ascent/ descent speed
6 m/s
Maximum horizontal flight speed
21 m/s
Maximum wind resistance
12 m/s
Maximum takeoff altitude
6,500 meters
Maximum flight time
54 minutes
Maximum range
43 kilometers
Image transmission distance
25 kilometers
Operating temperature range
-20℃ to 50℃
IP Protection Rating
IP55
Battery capacity
6768 mAh
Satellite navigation systems
GPS + BeiDou + Galileo + QZSS + GLONASS
Perception system type
Omnidirectional binocular vision system, supplemented by a 3D infrared sensor at the bottom of the fuselage
Hovering accuracy
Vertical
0.1 meter (when visual positioning is functioning properly)/
0.5 meter (when satellite positioning is functioning properly)/
0.1 meter (when RTK positioning is functioning properly)
Horizontal
0.3 meter (when visual positioning is functioning properly)/
0.5 meter (when satellite positioning is functioning properly)/
0.1 meter (when RTK positioning is functioning properly)
