| Item | SH0406C/B | SH0506C/B | SH0806C/B |
|---|---|---|---|
| Sensor | NHI1302C/B@BSI | ||
| Color | C: Colorful B: Black & White | ||
| Frame rate | 15/25/30/50/60fps, default 30fps | ||
| Effective illuminance | Colorful version: 0.0008lx@15fps, 0.001lx@30fps, 0.003lx@60fps Black & White version: 0.0004lx@15fps, 0.0006lx@30fps, 0.0008lx@60fps |
||
| Focal length | 4mm | 5mm | 8mm |
| Aperture | F1.0 | ||
| Resolution | Default 1280*1024, optional Setting: 1280*960, 1024*768, 800*640, 640*512 If need a special frame ratio, please contact the supplier |
||
| FOV | 1280*1024: H78.6°,V66.6° 1280*960: H78.6°,V63.3° 1024*768: H66.2°,V53.1° 800*640: H53.1°,V44.8° 640*512: H44.8°,V37° |
1280*1024: H68.8°,V58.1° 1280*960: H68.8°,V63.3° 1024*768: H58.1°,V46.6° 800*640: H46.6°,V39.3° 640*512: H39.3°,V32.5° |
1280*1024: H42.2°,V35.3° 1280*960: H42.2°,V33.6° 1024*768: H34.6°,V27.6° 800*640: H27.6°,V23.2° 640*512: H23.2°,V19.1° |
| Dynamic Range | Default 72dB; Upgradeable multi-mode WDR | ||
| Exposure mode | Rolling shutter | ||
| Boot Time | ~8s | ||
| Gain | Automatic | ||
| Lens Interface | M16 | ||
| Internal Storage | Default 32G, Maximum 128G | ||
| Output | UVC | ||
| Coding | H.264 / H.265, Default H.264 | ||
| Code rate | 3Mbps@CBR | ||
| Protocol | V4L2 | ||
| Software Version | NHUSB1.3 or above | ||
| Functions | Photography, video recording, resolution adjustment, frame rate adjustment, encoding settings, exposure control, USB flash drive mode | ||
| Interface | USB-1.25-5P | ||
| Size | See the figure below | ||
| Weight | ≤28g | ||
| Working Voltage | 5V±0.5V | ||
| Power Supply Interface | USB-1.25-5P | ||
| Power Consumption | Normal temperature 0.92W@25fps, 1.15W@50fps | ||
| Working Temperature | -40°C~+60°C | ||
| Storage Temperature | -50°C~+70°C | ||
